15KHZ 2600W Ultrasonic Welding Standard Machine for Welding Consumables
Specification
| Model | MY-PT02-1526-S |
| Frequency | 15k |
| Power | 2600w |
| Voltage | 110v/220v |
| Welding Air Pressure | 0.1~0.7Mpa |
| Welding time | 0.01-9.99s |
| Weight | 120kg |
| Machine Size | 400*650*1180mm |
| Warranty | 1 year |
| Service | OEM/ODM |
| Driven Type | Pneumatic air Pipe diameter 8mm |
Features
1. Classical analog type ultrasonic welder, simple operation.
2. Quick application changeover, high welding seam strength.
3. Suitable for high cadences and short cycle times production needs.
4. Solid-steel structure design can last for multiple decades.
5. Imported Pneumatic parts guarantee the stable welding.
6. High quality transducer and booster, durable and stable.
7. Over-Current self-protection
Competitive Advantage
△ High efficiency---It only takes 0.1-3 seconds at each time.
△ High strength---Weld joints can withstand big tensile force and high pressure.
△ High quality---Weld joints are water-tight and air-proof; airtight operation is guaranteed.
△ Economy---Keep costs down and reduce manpower by getting rid of screws and glue.
Factory Show
Certification and Patents
FAQ
A: Yes, we can. The mould could be customized based on your samples, the voltage can be 110V or 220V, the plug can be replaced with yours before shipment.
A: Normally it will takes 3-15 days, depends on your product and the order urgency.
A: After receipt the 3D drawings and samples, the mould ready date is 3-5 days
